PVE52

Comfortable

Wheelchair Friendly

Decorative

The largest Residential Elevator model available, the PVE52 is the perfect choice for those in need of a Wheelchair Accessible Residential Elevator or wheelchair lift. With it’s quick installation, innovative design and minimal pre-construction requirements, this Three-Passenger Residential Elevator offers everything you need in a residential elevator.

Overview Technical Specifications

No Machinery necessary

This is the largest of the three vacuum elevators, capable of carrying three people or two people if one is in a wheelchair. Even our largest lift takes up less space in your home than other traditional elevators. Like all other vacuum elevators, the PVE52 does not need a separate space for machinery or additional room above and below the lift for a pit. Since the unit has a self-supporting structure, you will not have to add a frame to your home before installing it. This means you can fit this lift anywhere in your home!

ECO-Friendly: Plug & Play Residential Elevator

Don’t forget that this vacuum elevator model won’t be costly in your electric bills. As an environmentally-friendly home elevator, the only electrical required to power it is 220V, 35 Amp, single phase service. This wheelchair-accessible residential elevator maintains all of the safety and technology features that the other PVE models have as well. Should a power outage occur, the vacuum lift safely descends to the lowest level and the mechanical door lock enables the passenger to exit, preventing passengers from getting stuck. The cabin is equipped with an LED light as well as a cabin fan that circulates the ambient air throughout the elevator car.

Wheelchair Accessible Home Elevator

The PVE52 can be set up to have between two to five stops, which means it can be used in homes up to five stories or a total of 15m. It has an external cylinder diameter of 132cm. Inside the unit measures a roomy 110cm in diameter. This provides enough space for a person in a wheelchair with an attendant or for up to three adults to stand in comfort. The cabin height is 2m, which is tall enough for provide headroom for most people. Rolling a wheelchair through the 82cm wide entrance opening is easy to do! With same side or opposite side door offerings, the largest of the residential vacuum elevators can be configured to accommodate almost any elevator installation.

Elegant Design , Panoramic View

There are many options for wheelchair-accessible elevators or wheelchair lifts, but only the PVE52 gives you the space you need, the safety features you require, and a design that compliments your home’s decor. When you or a loved one needs help getting around in your home, installing a residential wheelchair lift is a good choice.

Capacity

238 Kilograms

Outer diameter

1399 Millimeter

Number of Stops

2 | 5 M

Rated Speed

0.10 m/s

No pit, hoist way or machine room required	Self supporting structure
15m total rise max.	0.10m/s travelling speed
238kg rated load	2 - 5 stops
External cylinder diameter: 1399mm	Internal cabin diameter: 1118mm
Internal cabin height: 2007mm	Entrance way opening: 813mm
Weight of unit: 920kg for 2.8m ceiling	Through floor or Balcony/Stairway Mount landings
Power supply: 35A 200V AC	Aluminium and polycarbonate cylinder structure
Automatic interior LED lightning and fan	Mechanical emergency safety brake system
ASME A17.7 Certified
